The TBM750-53KUIF is a high-voltage three-phase bidirectional power module designed for efficient AC-DC energy conversion in high-efficiency and high-density applications. With a rated output capacity of 53kW and a voltage range of 750VDC, it supports both AC to DC and DC to AC conversion, ideal for a wide range of industrial and energy-related applications.
Utilizing advanced soft-switching technology, the TBM750-53KUIF ensures smooth operation with an impressive peak efficiency of 96% in the AC to DC direction and 95% in the DC to AC direction. It also boasts a high power factor (>0.99) and low total harmonic distortion (THDi <5%), ensuring a stable, reliable, and clean power supply.
Table of Contents
Overview of the TBM750-53KUIF
The TBM750-53KUIF is a state-of-the-art bidirectional power module designed to convert AC to DC and DC to AC seamlessly. With a 53kW rated output and operating at a high voltage of 750VDC, it excels in high power density applications that demand exceptional efficiency and minimal harmonic distortion. The module operates with a high power factor (>0.99) and low total harmonic distortion (THDi <5%), making it a reliable choice for both AC-DC and DC-AC applications. Thanks to advanced soft-switching technology, it ensures high reliability and energy efficiency.
Key Features of the TBM750-53KUIF
- Bidirectional Energy Conversion: Supports both AC to DC and DC to AC conversion, offering versatile power delivery.
- High Output Capacity: Rated output capacity of 53kW with 750VDC operation, ensuring efficient energy conversion.
- High Efficiency: 96% efficiency (AC to DC) and 95% efficiency (DC to AC), ensuring optimal energy use.
- Low Ripple Voltage: Ripple voltage ≤2%, delivering stable and clean power output.
- Modular Design: Features modular construction, enabling easy expansion and automatic parallel operation.
- Fault Protection: Advanced fault protection to enhance long-term reliability and safety.
- Environmental Adaptability: Capable of operating in harsh environments and unstable grid conditions with no derating up to 45°C.
- International Standards Compliance: Meets IEC62477-1 and EN55032 standards, and is UL, CE, and TUV certified.
Applications and Use Cases
The TBM750-53KUIF is well-suited for a wide variety of applications, including:
- Battery Pack Testing: Provides reliable power for testing battery systems, ensuring efficiency and accuracy.
- Bidirectional Power Testing: Ideal for applications where power must flow in both directions with high efficiency.
- Energy Recycling and Power Aging: Suitable for use in energy recycling systems, promoting longevity and sustainability of energy solutions.
- Grid-connected Systems: Efficiently integrates with grid-connected energy systems for optimal energy management.
To explore the best ways to incorporate the TBM750-53KUIF into your applications, refer to our Bidirectional Power Supply Selection Guide.
Frequently Asked Questions
1. What is the peak efficiency of the TBM750-53KUIF?
The TBM750-53KUIF achieves a peak efficiency of 96.0% in the AC to DC direction and 95.0% in the DC to AC direction.
2. Can the TBM750-53KUIF operate in harsh environments?
Yes, the module is designed for use in unstable grids and harsh environments, with no derating up to 45°C.
3. Is the TBM750-53KUIF compliant with international standards?
Yes, the module complies with IEC62477-1 and EN55032 standards and has passed UL, CE, and TUV certifications.
4. What applications are best suited for the TBM750-53KUIF?
The TBM750-53KUIF is ideal for battery pack testing, bidirectional power testing, energy recycling, and integration into grid-connected systems.
Explore the TBM750-53KUIF
To learn more about how the TBM750-53KUIF can enhance your energy systems, visit our product page:
